BeckhoffBeckhoff EK1814
The Beckhoff EK1814 is an EtherCAT coupler with integrated digital inputs and outputs, acting as a link between the EtherCAT protocol on the fieldbus level and EtherCAT terminals. It features four digital inputs, four digital outputs, and two RJ45 bus interfaces. The system and field supply operate at 24 V DC, and the unit is housed in a compact High Density casing with IP20 protection.
Beckhoff
EK1814
Industrial component
PROCUREMENT NOTE
Accurate identification before quotation
The complete Beckhoff EK1814 reference is used as the starting point for sourcing. Price, availability, lead time and application-specific compatibility are confirmed during quotation review.
14 manufacturer-verified details shown below, with 1 more reference field confirmed on RFQ.
TECHNICAL DATA AND EVIDENCE
Technical properties and reference data
| Property | Value | Evidence |
|---|---|---|
| Material | Polycarbonat | Manufacturer verifiedChecked 2026-08-02 |
| Dimensions | 44 x 100 x 67 mm | Manufacturer verifiedChecked 2026-08-20 |
| anzahl der ethercat klemmen im gesamtsystem | bis zu 65.535 | Manufacturer verifiedChecked 2026-08-20 |
| ausgangsstrom max | 0,5 A | Manufacturer verifiedChecked 2026-08-20 |
| betriebstemperatur | -25…+60 °C | Manufacturer verifiedChecked 2026-08-20 |
| lagertemperatur | -40…+85 °C | Manufacturer verifiedChecked 2026-08-20 |
| product description tr | Beckhoff markasına ait EK1814 parça kodlu endüstriyel bileşen, polikarbonat malzemeden üretilmiş gövde yapısına sahiptir. Ürün, iki adet RJ45 soket bağlantısı ile 100 metreye kadar bağlantı uzunluğu ve toplam sistemde 65.535'e kadar EtherCAT klemmesi desteği sunar. 24 V DC anma gerilimi ile çalışan bu bileşen, dört adet giriş ve dört adet çıkış barındırır. IP20 koruma sınıfındaki cihaz, -25 ile +60 derece arasındaki işletme sıcaklığı aralığında güvenle kullanılabilir. | Reference recordChecked 2026-08-26 |
| schutzart | IP20 | Manufacturer verifiedChecked 2026-08-20 |
| signalspannung 0 | -3…+5 V | Manufacturer verifiedChecked 2026-08-20 |
| signalspannung 1 | 11…30 V | Manufacturer verifiedChecked 2026-08-20 |
| stromaufnahme aus u p | 40 mA + Last | Manufacturer verifiedChecked 2026-08-20 |
| stromaufnahme aus u s | 100 mA + (∑ E-Bus-Strom/4) | Manufacturer verifiedChecked 2026-08-20 |
| stromversorgung e bus | 1000 mA | Manufacturer verifiedChecked 2026-08-20 |
| verbindungsl ngen | bis zu 100 m | Manufacturer verifiedChecked 2026-08-20 |
| verbindungstechnik | 2 x RJ45-Buchse | Manufacturer verifiedChecked 2026-08-20 |
Revisions and regional variants may exist. Send an RFQ with the exact part number and quantity for final confirmation.
Request technical confirmation →RELATED BECKHOFF REFERENCES
More Beckhoff part-number records
STOCK & WORLDWIDE DELIVERY
Warehouse stock review and door-to-door delivery
Stock for Beckhoff EK1814 is reviewed against warehouse and supplier-side options (US, Germany, Türkiye, Dubai), with worldwide door-to-door delivery and export terms confirmed in the written quotation. See global operations for the full process.
REQUEST THIS EXACT REFERENCE
RFQ for Beckhoff EK1814
Price, availability and lead time are confirmed only after the exact reference, requested quantity and delivery destination are reviewed. Axiparts is an independent industrial sourcing platform unless a written quotation states otherwise.
Beckhoff EK1814 FAQ
What is Beckhoff EK1814?
The Beckhoff EK1814 is an EtherCAT coupler with integrated digital inputs and outputs, acting as a link between the EtherCAT protocol on the fieldbus level and EtherCAT terminals. It features four digital inputs, four digital outputs, and two RJ45 bus interfaces. The system and field supply operate at 24 V DC, and the unit is housed in a compact High Density casing with IP20 protection.
What are the technical specifications of Beckhoff EK1814?
Material: Polycarbonat; Dimensions: 44 x 100 x 67 mm; anzahl der ethercat klemmen im gesamtsystem: bis zu 65.535; ausgangsstrom max: 0,5 A; betriebstemperatur: -25…+60 °C; lagertemperatur: -40…+85 °C; schutzart: IP20; signalspannung 0: -3…+5 V. The full manufacturer specification is confirmed during RFQ review.
